The technical Data Sheet of the rubber running track surfaces.
- Share
- Issue Time
- Jan 28,2021
NovoTrack's Honor
NovoTrack prefabricated rubber track surfaces have been certificated by IAAF and CAA(Chinese Athletics Association).We were CAA's officially appointed supplier for the prefabricated rubber surfaces(2014-2017) and were the winner of the "Golden Track Surfaces Award".We have acquired multiple management system certification such as ISO9001,ISO14000 and OHSMS18000,along with the environment protection Class II Certificate.Our products have also passed the tests conducted by the appointed labs and are proven to be compliant with the physical and chemical standards within the newly published national standars GB36246-2018<synthetic surface materials used for school stadium and playground.
Physical performance testing
Property | Test method(IAAF) | Specified range(IAAF) | Test Report |
Force Reduction | GB 36246-2018 | 35-50 | 38.8 |
|
Vertical Deformation |
GB 36246-2018 |
0.6-3.0
|
1.8
|
Skid Resistance | GB 36246-2018 | ≥47 | 49 |
|
Tensile Strength |
GB 36246-2018 |
≥0.5 |
0.76
|
|
Elongation at Break |
GB 36246-2018 |
≥40 |
162.3
|
|
Fire Rating |
GB 36246-2018 |
1 |
1
|
Chemical performance testing
|
Release of harmful substances |
Property
|
Specified range(IAAF)
|
Test Report
|
|
|
Formaldehyde/[mg/(㎡-h)]
|
≤0.4
|
0.047
|
||
|
Benzene[mg/(㎡-h)]
|
≤0.1
|
not detected
|
||
|
Carbon disulfide[mg/(㎡-h)]
|
≤7.0
|
not detected
|
||
Please contact us for more data...
